10.1-98 "Ukuran Panel Cerah Tinggi LCD Tampilan dengan 700-5000 Typ. Cerah

  • 10.1-98" Panel Size High Brightness LCD Display with 700-5000 Typ. Brightness
  • 10.1-98" Panel Size High Brightness LCD Display with 700-5000 Typ. Brightness
  • 10.1-98" Panel Size High Brightness LCD Display with 700-5000 Typ. Brightness
  • 10.1-98" Panel Size High Brightness LCD Display with 700-5000 Typ. Brightness
  • 10.1-98" Panel Size High Brightness LCD Display with 700-5000 Typ. Brightness
Tempat asal Shenzhen
Nama merek ROGIN
Kuantitas min Order 5
Harga Price is negotiable.
Kemasan rincian Karton Atau Kotak Kayu
Waktu pengiriman 6-8 minggu
Syarat-syarat pembayaran T/T, L/C
Menyediakan kemampuan Kecukupan titik

Hubungi saya untuk sampel gratis dan kupon.

ada apa:0086 18588475571

Wechat wechat: 0086 18588475571

skype: sales10@aixton.com

Jika Anda memiliki masalah, kami menyediakan 24 jam bantuan online.

x
Detail produk
Ukuran Panel 10.1-98 " Cahaya 700-5000 (Typ.)
Menyoroti

700-5000 Tipe. Kecerahan Layar LCD

,

10.1-98 Panel Size LCD Display

,

Layar LCD Kecerahan Tinggi
Tinggalkan pesan
Deskripsi Produk

Katalog Produk Layar LCD Cerah Tinggi

Jenis tepi:

Ukuran Model Cahaya Resolusi Atas ((°C) AA ((mm) OD ((mm) I/F Kontras
15.6 LCMA-RX0156GB05-C060 600 3840*2160 0 ~ 50 345.6*194.4 353*210.1*4.2 eDP 1000:1
15.6 LCMA-RX0156GI06-C050 500 1920X1080 0 ~ 60 344.16*193.59 350.66*205.78*2.89 LVDS 1500:1
17.0 LCMA-RX0170GA02-C100 1000 1280*1024 (0-50) 337.92 kali 270.336 358.5*296.5*10.3 LVDS (2 ch, 8-bit) 1000:1
18.5 LCMA-RX0185GB06-C100 1000 1920*1080 (0-50) 408.96*230.04 430.37*254.6*11.2 LVDS (2 ch, 8-bit) 1000:1
18.5 LCMA-RX0185GB10-C050 500 1920*1080 (0-50) 409.8*230.04 431 kali 255 kali 9.2 LVDS 1000:1
19.0 LCMA-RX0190GB01-C050 500 1280*1024 (0-50) 374.784*299.82 396*324*10.4 LVDS (2 ch, 8-bit) 1200:1
21.5 LCMA-RX0215GL01-C070 700 1920*1080 (0-50) 476.064*267.786 497.6*292.2*10.5 LVDS (2 ch, 8-bit) 1000:1
21.5 LCMA-RX0215GB02-C100 1000 1920*1080 (-20-80) 476.64 x 268.11 495.6*292.2*11.3 LVDS (2 ch, 8-bit) 1000:1
23.8 LCMA-RX0238GA01-C150 1500 1920*1080 (0-50) 527.04*296.46 557.2*326.6*17.5 LVDS (2 ch, 8-bit) 3000:1
23.8 LCMA-RX0238GI01-C085 850 1920*1080 (0-50) 527.04*269.46 543*317.4*11.1 LVDS (2 ch, 8-bit) 1000:1
27.0 LCMA-RX0270GA07-C070 700 1920*1080 (0-50) 597.6*336.15 613.6*356.85*10.5 LVDS (2 ch, 8-bit) 3000:1
27.0 LCMA-RX0270GA10-C050 500 1920*1080 (0-50) 597.6*336.15 613.6*356.85*10.5 LVDS (2 ch, 8-bit) 3000:1
27.0 LCMA-RX0270GA11-C150 1500 1920*1080 (0-50) 597.6*336.14 628*366.4*23.7 LVDS (2 ch, 8-bit) 3000:1
27.0 LCMA-RX0270GB01-C100 1000 1920*1080 (0-50) 597.888*336.312 611.5*335.8*13.2 LVDS (2 ch, 8-bit) 1000:1
27.0 LCMA-RX0270GB06-C070 700 1920*1080 (0-50) 597.888*336.312 611.5*355.8*15.2 LVDS (2 ch, 8-bit) 1000:1
32.0 LCMA-RX0320GA02-C100 1000 1920*1080 (0-50) 698.4*392.84 729.4*424.2*29.5 LVDS (2 ch, 10-bit) 3000:1
32.0 LCMA-RX0320GI01-C100 1000 3840*2160 (0-50) 698.4*392.85 751.5*446.01*30.5 V-by-One 8 jalur 3000:1
32.0 LCMA-RX0320GI04-C100 1000 3840*2160 (0-50) 698.4*392.85 751.5*446.01*30.5 V-by-One 8 jalur 3000:1
43.0 LCMA-RX0430GL01-C150 1500 1920*1080 (0-50) 941.184 kali 529.416 973.2*561.5*29.5 LVDS (2 ch, 8-bit) 1000:1
43.0 LCMA-RX0430GL10-C150 1500 1920*1080 (0-50) 941.184 kali 529.416 973.2*561.5*29.5 LVDS (2 ch, 8-bit) 1000:1
43.0 LCMA-RX0430GB12-C050 500 3840*2160 (0-50) 941.18 x 529.42 973.2*561.5*20.3 V-by-One 8 jalur 1200:1
43.0 LCMA-RX0430GR02-C040 400 1920*1080 (0-50) 941.8 kali 529.42 961*549.7*17.1 LVDS (2 ch, 8-bit) 1200:1
49.0 LCMA-RX0490GL09-C250 2500 1920*1080 (0-50) 1073.78*604 1103.8*634*31.5 LVDS (2 ch, 8/10-bit) 1300:1
49.0 LCMA-RX0490GL10-C150 1500 3840*2160 (0-50) 1073.78*604 1103.8*634*31.5 V-by-One 8 jalur 1100:1
49.0 LCMA-RX0490GB03-C060 500 3840*2160 (0-50) 1073.78*604 1095.18*630.1*13.8 LVDS (2 ch, 8/10-bit) 1200:1
55.0 LCMA-RX0550GR03-C070 700 3840*2160 (0-50) 1209.6 kali 680.4 1233.8*704.6*17.7 V-by-One 8 jalur 1300:1

Tipe langsung:

Ukuran Model Cahaya Resolusi Atas ((°C) AA ((mm) OD ((mm) I/F Kontras
23.8 LCMA-RX0238GA02-Z350 3500 1920*1080 (0-50) 527.04*269.46 554.04*323.53*41 LVDS (2 ch, 8-bit) 3000:1
27.0 LCMA-RX0270GL06-Z080 800 3840*2160 (0-50) 596.74 kali 335.66 626*364.4*24 LVDS (2 ch, 8-bit) 1000:1
27.0 LCMA-RX0270GA15-Z150 1500 1920*1080 0 ~ 50 597.89*336.31 620*359.69*20.1 LVDS (2 ch, 8-bit) 3000:1
32.0 LCMA-RX0320GL17-Z080 800 3840*2160 (0-50) 697.31*292.23 727*421*28.9 eDP (4 jalur) 1300:1
32.0 LCMA-RX0320GL24-Z150 1500 1920*1080 0 ~ 50 698.4*392.85 731.9*431.4*53.8 LVDS 1200:1
43.0 LCMA-RX0430GL19-Z100 1000 3840*2160 (0-50) 941.18 x 529.42 973.8*567*58.4 V-by-One 8 jalur 1100:1
43.0 LCMA-RX0430GL13-Z200 2000 1920*1080 (0-50) 940.9 kali 529.3 973.8*567*58 LVDS (2 ch, 8-bit) 1200:1
49.0 LCMA-RX0490GL04-Z250 2500 1920*1080 (0-50) 1073.8*604 1098*628*55 LVDS (2 ch, 8-bit) 1000:1
49.0 LCMA-RX0490GL14-Z350 3500 3840*2160 (0-50) 1073.78*604 1106.4*641.6*57.5 V-by-One 8 jalur 1100:1
55.0 LCMA-RX0550GB10-Z200 2000 1920*1080 (0-50) 1209.6 kali 680.4 1242.1*718*56.1 LVDS (2 ch, 10-bit) 1200:1
55.0 LCMA-RX0550GB14-Z200 2000 1920*1080 (0-50) 1209.6 kali 680.4 1242.1*718*56.1 LVDS (2 ch, 10-bit) 1200:1
55.0 LCMA-RX0550GL24-Z200 2000 1920*1080 (0-50) 1209.6 kali 680.4 1242.1*718*58.1 V-by-One 8 jalur 1300:1
55.0 LCMA-RX0550GL30-Z300 3000 1920*1080 (0-50) 1209.6 kali 680.4 1242.1*718*58.1 LVDS (2 ch, 8-bit) 1000:1
65.0 LCMA-RX0650GL04-Z200 2000 1920*1080 (0-50) 1428.48 kali 803.52 1452.4*827.5*59 V-by-One 8 jalur 1300:1
65.0 LCMA-RX0650GL05-Z200 2000 3840*2160 (0-50) 1428.5*803.5 1461*843.1*59.5 V-by-One 8 jalur 1100:1
65.0 LCMA-RX0650GB08-Z200 2000 1920*1080 (0-50) 1428.5*803.5 1461*843.1*59.5 V-by-One 8 jalur 1200:1
75.0 LCMA-RX0750GL02-Z200 2000 3840*2160 (0-50) 1649.66*927.94 1689*971*66.15 V-by-One 8 jalur 1200:1
86.0 LCMA-RX0860GL03-Z100 1000 3840*2160 (0-50) 1895.04*1065.94 1933*1108.5*72.1 V-by-One 8 jalur 1200:1
86.0 LCMA-RX0860GL04-Z200 2500 3840*2160 (0-50) 1895.04*1065.94 1933*1108.5*72.1 V-by-One 8 jalur 1200:1

Tipe tepi (((suhu luas):

Ukuran Model Cahaya Resolusi Atas ((°C) AA ((mm) OD ((mm) I/F Kontras
10.1 LCMA-RX0101GI02-C120 1200 1280*800 (-20-70) 216.96 kali 135.6 230.7*152.55*7 LVDS (1 ch, 6/8-bit) 800:1
10.1 LCMA-RX0101GI01-C100 1000 1280*800 (-20-70) 216.96 kali 135.6 229.46*149.1*7.7 LVDS (1 ch, 8-bit) 800:1
10.1 LCMA-RX101B-1000 1000 1280*800 (-20-70) 216.96 kali 135.6 229.46*149.1*7.7 LVDS (1 ch, 8-bit) 1000:1
10.4 LCMA-RX0104GR02-C150 1500 1024*768 (-30-80) 210.43 kali 157.824 227*175.8*9.2 LVDS (1 ch, 6/8-bit) 900:1
12.1 LCMA-RX0121GI01-C150 1500 1280*800 (-20-70) 261.12*163.2 278*184*11 LVDS ((1 ch, 6/8-bit) 1000:1
12.1 LCMA-RX0121GR01-C100 1000 1024*768 (-30-80) 245.76*184.32 260.5*204*8.46 LVDS ((1 ch, 6/8-bit) 1000:1
12.1 LCMA-RX0121GR03-C150 1500 1280*800 (-20-70) 261.12*163.2 277.7*180.6*9.5 LVDS (1 ch, 6/8-bit) 1200:1
12.1 LCMA-RX0121GB02-C050 500 1024*768 (-20-70) 245.76*184.32 260.5*204*9.2 LVDS (1 ch, 6/8-bit) 1200:1
13.3 LCMA-RX0133GB02-C080 800 1920*1080 (-20-70) 293.76 kali 165.24 307.6*183.05*6.7 eDP (2 jalur) 800:1
13.3 LCMA-RX0133GB03-C100 1000 1920*1080 (-20-70) 293.76 kali 165.24 307.6*183.05*7.28 eDP (2 jalur) 800:1
15.0 LCAM-RX0150GB05-C150 1500 1024*768 (-20-70) 304.128 kali 228.096 326.5*253.5*9.7 LVDS (1 ch, 8-bit) 1000:1
15.0 LCMA-RX0150GB03-C100 1000 1024*768 (-20-70) 304.128 kali 228.096 326.5*253.5*9.7 LVDS (1 ch, 8-bit) 1000:1
15.0 LCMA-RX0150GR01-C150 1500 1024*768 (-20-70) 304.128 kali 228.096 326.5*253.5*9.7 LVDS (1 ch, 8-bit) 1000:1
15.0 LCMA-RX0150GI01-C100 1000 1024*768 (-20-70) 304.128 kali 228.096 326.5*253.5*9.6 LVDS (1 ch, 6/8-bit) 2000:1
15.0 LCMA-RX0150GI02-C100 1000 1024*768 (-30-80) 304.128 kali 228.096 326.5*253.5*9.6 LVDS (1 ch, 6/8-bit) 2500:1
15.6 LCMA-RX0156GA02-C100 1000 1920*1080 (-20-70) 344.16*193.59 363.8*215.9*8.8 eDP (2 jalur) 1000:1
15.6 LCMA-RX0156GI01-C100 1000 1920*1080 (-20-70) 344.16*193.59 360*212.3*6.3 eDP (2 jalur) 1000:1
15.6 LCMA-RX0156GB03-C100 1000 1920*1080 (0-70) 344.16*193.59 363.8*216*9.6 LVDS (2 ch, 8-bit) 1200:1
17.0 LCAM-RX0170GA06-C110 1100 1280*1024 (-30-85) 337.920 kali 270.336 358.5*296.5*9.10 LVDS (2 ch, 8-bit) 800:1
17.3 LCMA-RX0173GA01-C080 800 1920*1080 (0-70) 381.888*214.812 403*240*13 LVDS (2 ch, 8-bit) 600:1
18.5 LCMA-RX0185GB03-C120 1200 1920*1080 (-30-80) 408.96*230.04 430.4*256.6*12 LVDS (2 ch, 8-bit) 1200:1
18.5 LCMA-RX0185GA04-C100 1000 1920*1080 (-20-70) 408.96*230.04 430.4*254.6*12.5 LVDS (2 ch, 8-bit) 1000:1
21.5 LCMA-RX0215GB26-C150 1500 1920*1080 (-20-70) 476.64 x 268.11 504.2*295*15.5 LVDS 1000:1
21.5 LCMA-RX0215GB08-C150 1500 1920*1080 (-20-70) 476.64 x 268.11 502.8*299.18*16 LVDS (2 ch, 8-bit) 1000:1
21.5 LCMA-RX0215GB28-Z150 1500 1920*1080 (-20-70) 476.64 x 268.11 496*292.5*15.9 LVDS 1000:1
21.5 LCMA-RX0215GB16-C100 1000 1920*1080 (-20-70) 476.64 x 268.11 495.6*292.2*9.5 LVDS (2 ch, 8-bit) 1000:1
24.0 LCMA-RX0240GA01-C100 1000 1920*1080 (-20-70) 531.36*298.89 556*323.2*17 LVDS (2 ch, 8-bit) 5000:1
32.0 LCMA-RX0320GB01-C150 1500 1920*1080 (-20-70) 698.4*392.85 729.4*424.2*29.5 LVDS (2 ch, 8-bit) 1200:1
32.0 LCMA-RX0320GB17-C150 1500 1920*1080 (-20-70) 698.4*392.85 729.4* 424.2* 29.5 LVDS 1200:1
32.0 LCMA-RX0320GP01-C005 50 1920*1080 (-20-70) 696.96*392.04 734*420*17.7 eDP (2 jalur) 17:1
32.0 LCMA-RX0320GL18-C120 1200 1920*1080 (-20-70) 698.4*392.85 729.4*424.2*29.5 LVDS (2 ch, 8-bit) 1300:1
43.0 LCMA-RX0430GB02-C150 1500 1920*1080 (-20-70) 941.18 x 529.42 973.2*561.5*29.5 LVDS (2 ch, 8-bit) 1200:1
55.0 LCMA-RX0550GB03-C150 1500 1920*1080 (-30-80) 1209.6 kali 680.4 1243*725.4*36.7 LVDS (2 ch, 10-bit) /

Tipe langsungsuhu luas):

Ukuran

Model

 Cahaya Resolusi Di atas AA ((mm) OD ((mm) I/F Kontras
18.5 LCMA-RX0185GB09-Z150 1500 1920*1080 ¥ 30 ~ 80 408.96*230.04 431*255*11 LVDS 1200:1
18.5 LCMA-RX0185GB09-Z250 2500 1920*1080 (-20-70) 476.64 x 268.11 504.2*295*15.5 LVDS 1000:1
21.5 LCMA-RX0215GB28-Z150 1500 1920*1080 (-20-70) 476.64 x 268.11 496*292.5*15.9 LVDS 1000:1
21.5 LCMA-RX0215GB21-Z500 5000 1920*1080 (-20-70) 476.6 x 268.1 502.82*294.26*36.2 LVDS (2 ch, 8-bit) 1000:1
23.8 LCMA-RX0238GB03-Z150 1500 1920*1080 (-20-70) 527.04*296.46 550 kali 320 kali 20.1 LVDS (2 ch, 8-bit) 1000:1
32.0 LCMA-RX0320GB06-Z200 2000 1920*1080 (-20-70) 698.4*392.85 731.9*431.4*56 LVDS (2 ch, 8-bit) 1200:1
32.0 LCMA-RX0320GL20-Z200 2000 1920*1080 (-20-70) 698.4*392.85 731.9*431.4*56 LVDS (2 ch, 8-bit) 1300:1
43.0 LCMA-RX0430GB03-Z200 2000 1920*1080 (-20-70) 940.896 kali 529.254 965.2*553.4*55 LVDS (2 ch, 8-bit) 1200:1
43.0 LCMA-RX0430GB07-Z250 2500 1920*1080 (-20-70) 940.9 kali 529.25 973.8*567*56.4 LVDS (2 ch, 8-bit) 1200:1
43.0 LCMA-RX0430GB13-Z350 3500 1920*1080 (-20-70) 940.9 kali 529.25 966.8 kali 554.8 kali 60.7 LVDS (2 ch, 8-bit) 1200:1
55.0 LCMA-RX0550GB07-Z200 2000 1920*1080 (-20-70) 1209 kali 680.4 1233.6*704.4*55 LVDS (2 ch, 10-bit) 1000:1
55.0 LCMA-RX0550GL32-Z200 2000 1920*1080 (-20-70) 1209.6 kali 680.4 1242.1*718*58.1 V-by-One 8 jalur 1300:1
55.0 LCMA-RX0550GL25-Z350 3500 1920*1080 (-20-70) 1209 kali 680.4 1233.6*704.4*55 V-by-One 8 jalur 1300:1
55.0 LCMA-RX0550GB09-Z250 2500 1920*1080 (-30-80) 1209.6 kali 680.4 1242.1*718*56.1 LVDS (2 ch, 8/10-bit) /
65.0 LCMA-RX0650GB04-Z200 2000 3840*2160 (-30-80) 1428.48 kali 803.52 1452.4*827.5*61 V-by-One 8 jalur 1200:1
65.0 LCMA-RX0650GB04-Z260 2600 3840*2160 (-30-80) 1428.48 kali 803.52 1452.4*827.5*61 V-by-One 8 jalur 1200:1
65.0 LCMA-RX0650GB10-Z350 3500 3840*2160 (-30-80) 1428.48 kali 803.52 1454*828.7*58.6 V-by-One 8 jalur 1200:1
75.0 LCMA-RX0750GB02-Z350 3500 3840*2160 (-30-80) 1649.7*927.9 1683*975.4*55.3 V-by-One 8 jalur 1200:1

Keuntungan Produk ️

1.tomisasi 700-5000cd/m2.
2. Cahaya matahari di luar dapat dibaca.
3Konsumsi daya rendah.
4. Uniformitas tinggi sampai 85%.
5. Umur panjang, 50K jam ((Jenis), hingga 80K jam
6Struktur lampu latar aluminium dengan disipasi panas yang baik.
7.Bentang suhu yang luas hingga -30°C-80°C.
8.Resistensi kejut tinggi dan stabilitas tinggi.

Aplikasi produk ️

1- Papan rambu-rambu stasiun bus.
2.Intelligent Charging Pile.
3. Outdoor Elektronik Berita Reading Board.
4- Kabinet Ekspres yang cerdas.
5- Mesin penjual otomatis.
6Mesin Iklan Komersial.
7.Informasi Mesin Inquiry atraksi.
8- Dewan Informasi Komunitas.
10.1-98 "Ukuran Panel Cerah Tinggi LCD Tampilan dengan 700-5000 Typ. Cerah 0 10.1-98 "Ukuran Panel Cerah Tinggi LCD Tampilan dengan 700-5000 Typ. Cerah 1 10.1-98 "Ukuran Panel Cerah Tinggi LCD Tampilan dengan 700-5000 Typ. Cerah 2 10.1-98 "Ukuran Panel Cerah Tinggi LCD Tampilan dengan 700-5000 Typ. Cerah 3



️Katalog produk layar LCD dengan kecerahan tinggi.pdf...
