Tampilan LCD Tipe Bar Cerah Tinggi dalam 9-88 "Ukuran Panel dan 500-2500 Tipe Cerah

  • High Brightness Bar Type LCD Display in 9-88" Panel Size and 500-2500 Typ. Brightness
  • High Brightness Bar Type LCD Display in 9-88" Panel Size and 500-2500 Typ. Brightness
  • High Brightness Bar Type LCD Display in 9-88" Panel Size and 500-2500 Typ. Brightness
  • High Brightness Bar Type LCD Display in 9-88" Panel Size and 500-2500 Typ. Brightness
  • High Brightness Bar Type LCD Display in 9-88" Panel Size and 500-2500 Typ. Brightness
Tempat asal Shenzhen
Nama merek ROGIN
Kuantitas min Order 5
Harga Price is negotiable.
Kemasan rincian Karton Atau Kotak Kayu
Waktu pengiriman 6-8 minggu
Syarat-syarat pembayaran T/T, L/C
Menyediakan kemampuan Kecukupan titik

Hubungi saya untuk sampel gratis dan kupon.

ada apa:0086 18588475571

Wechat wechat: 0086 18588475571

skype: sales10@aixton.com

Jika Anda memiliki masalah, kami menyediakan 24 jam bantuan online.

x
Detail produk
Ukuran Panel 9-88 " Cahaya 500-2500 (Typ.)
Menyoroti

9-88 Bar Type LCD Display

,

Tampilan LCD Tipe Bar Cerah Tinggi
Tinggalkan pesan
Deskripsi Produk

Catalogue produk layar LCD tipe batang

Ukuran Model Cahaya Atas ((°C) Resolusi AA ((mm) OD ((mm) Kontras I/F
12.3 LCMA-RX0123TB02-C050 500 (-20-70) 1024*255 304.13*76.03 325.9*98.48*11.6 1000:1 LVDS (1 ch, 8-bit)
13.8 LCMA-RX0138TQ01-C070 700 (0-50) 1920*358 344.16*61.17 371.5*90.1*12.7 3000:1 LVDS (2 ch, 8-bit)
14.7 LCMA-RX0147TQ01-C050 500 (0-50) 1920*808 344.16x144.834 352*161*10 800:1 LVDS
14.9 LCMA-RX0149TB01-C050 500 (0-50) 1280*204 374.78*60 399.78*85*13 1000:1 LVDS (2 ch, 8-bit)
14.9 LCMA-RX0149TB03-C070 700 (0-50) 1280*204 374.78*60 399.78*81*12.88 1000:1 LVDS (2 ch, 8-bit)
15 LCMA-RX0150TB01-C030 300 (0-50) 1280*248 374.78 kali 72.61 396*100.8*12.58 1000:1 LVDS (2 ch, 8-bit)
15.1 LCMA-RX0151TB01-C060 600 (0-50) 1280*242 374.78 kali 70.86 394.8*85.5*16.2 1000:1 LVDS (2 ch, 8-bit)
15.3 LCMA-RX0153TB02-C070 700 (0-50) 1280*342 374.78 kali 100.14 396*124*13 1000:1 LVDS (2 ch, 8-bit)
16.3 LCMA-RX0163ZB01-C085 850 (0-50) 1366*203 409.8*61 38.7*90*30 1000:1 LVDS (1 ch, 8-bit)
16.3 LCMA-RX0163TA01-C080 800 (-20-70) 1920*285 408.96 kali 60.705 432 kali 85 kali 14.8 1000:1 LVDS (2 ch, 8-bit)
16.37 LCMA-RX1637TB01-C040 400 (0-50) 1366*238 409.8*71.4 431.8*95.6*15.1 1000:1 LVDS (1 ch, 8-bit)
16.4 LCMA-RX0164TB01-C070 700 (0-50) 1366*230 409.7*69 431.8*94.8*14.7 1000:1 LVDS (1 ch, 8-bit)
16.5 LCMA-RX0165TB01-C070 700 (0-50) 1366*286 409.8*86 437.8*114*15 1000:1 LVDS (1 ch, 8-bit)
16.7 LCMA-RX0167TB01-C040 400 (0-50) 1920*540 408.96*115 425.8*131.8*8 1000:1 LVDS (2 ch, 8-bit)
16.8 LCMA-RX0168TB01-C070 700 (0-50) 1366*384 409.7 kali 115.2 431.8*141*14.7 1000:1 LVDS (1 ch, 8-bit)
16.9 LCMA-RX0169TA02-C080 800 (-20-70) 1920*624 408.96*133 430.4*158.5*23.8 1000:1 LVDS (2 ch, 8-bit)
17 LCMA-RX0170TB01-C100 1000 (0-50) 1280*658 374.78*193 395.2*217.16*13.5 1000:1 LVDS (2 ch, 8-bit)
17.2 LCMA-RX0172TB01-C050 500 (0-50) 1366*510 409.8*153 430.4*178.4*12 1000:1 LVDS (1 ch, 8-bit)
17.2 LCMA-RX0172TB02-C050 500 (0-50) 1920*714 408.96 kali 152.1 439*179.3*19.15 1000:1 LVDS (2 ch, 8-bit)
19.1 LCMA-RX0191TA02-C070 700 (0-50) 1920*340 476.64*84.4 497.4*110.9*13.5 3000:1 LVDS (2 ch, 8-bit)
19.2 LCMA-RX0192TB01-C050 500 (-20-85) 1920*359 476.64*89.37 496*109.2*13.7 1000:1 LVDS (2 ch, 8-bit)
19.2 LCMA-RX0192TA02-C050 500 (0-50) 1920*360 476.64*89.37 496*109.2*11.88 3000:1 LVDS (2 ch, 8-bit)
19.4 LCMA-RX0194TA03-C100 1000 (0-50) 1920*510 476.64 kali 126.6 495.6*150.7*12 3000:1 LVDS (2 ch, 8-bit)
19.5 LCMA-RX0195TA02-C070 700 (0-50) 1920*536 476.64*133 496*149.6*12.2 3000:1 LVDS (2 ch, 8-bit)
19.6 LCMA-RX0196TB01-C100 1000 (-20-85) 1920*600 476.6*148.95 500 kali 173,45 kali 13.08 1000:1 LVDS (2 ch, 8-bit)
19.7 LCMA-RX0197TB01-C100 1000 (-20-85) 1920*624 476.64 kali 154.9 497.4*179.4*14.5 1000:1 LVDS (2 ch, 8-bit)
19.7 LCMA-RX0197TQ01-C060 600 (0-50) 1920*643 478.656 kali 260.28 497.4*179.4*13.07 3000:1 LVDS (2 ch, 8-bit)
21.6 LCMA-RX0216TL01-C040 400 (0-50) 669*899 328*441 351.97*465*14 1200:1 LVDS (2 ch, 8-bit)
21.6 LCMA-RX0216TL02-C040 400 (0-50) 1798*1338 328*441 351.97*465*14 1300:1 LVDS (2 ch, 8-bit)
21.9 LCMA-RX0219TA01-C100 1000 (0-50) 1920*712 527.04*195.5 548.4*222.2*14.5 3000:1 LVDS (2 ch, 8-bit)
21.9 LCMA-RX0219TA02-C100 1000 (0-50) 1920*860 509.18 x 228.1 537*256*15mm 1000:1 LVDS
23.9 LCMA-RX0239TA01-C070 700 (0-50) 1920*359 597.6*112 623.5*140*13.57 3000:1 LVDS (2 ch, 8-bit)
24 LCMA-RX0240GB02-C080 800 (0-50) 1920*360 597.888 kali 112.1 612.7*132.1*8.4 1200;1 LVDS (2 ch, 8-bit)
24.6 LCMA-RX0246TA01-C070 700 (0-50) 1920*578 597.6*180 623.5*208*13.57 3000:1 LVDS (2 ch, 8-bit)
27 LCMA-RX0270TL01-C050 500 (0-50) 1847*154 581.76 kali 363.6 650*438*29MM 1300:1 V-by-One 8 jalur
27.5 LCMA-RX0275TA01-C070 700 (0-50) 1920*136 698.4*50 714.4*75*19.2 4000:1 LVDS (2 ch, 8-bit)
28 LCMA-RX0280TA02-C100 1000 (-20-60) 1920*360 698.4 kali 130.95 698.4*167.3*17.2 4000:1 LVDS (2 ch, 8-bit)
28 LCMA-RX0280TA03-C100 1000 (0-50) 1920*360 698.4 kali 130.9 732*165*17.3 4000:1 LVDS (2 ch, 8-bit)
28.4 LCMA-RX0284TA01-C070 700 (0-50) 1920*511 698.4*186 727.4 * 215 * 19.3 4000:1 LVDS (2 ch, 8-bit)
28.8 LCMA-RX0288TA03-C070 700 (0-50) 1920*540 698.4*196.43 735.8*233.8*18.1 4000:1 LVDS (2 ch, 8-bit)
29 LCMA-RX0290GL01-C050 500 (0-50) 2560*1080 672.768*283.824 693.6*308.9*17 1000! LVDS (4 ch, 8-bit)
36.6 LCMA-RX0366TA01-C100 1000 (-20-60) 1920*290 919.3*139 956.9*176.5*17.9 4000:1 LVDS (2 ch, 8-bit)
36.6 LCMA-RX0366TA02-C100 1000 (-20-60) 1920*290 919.296*138.85 960*174.35*16.9 4000:1 LVDS (2 ch, 8-bit)
36.6 LCMA-RX0366TB01-C055 550 (-20-70) 1920*290 919.3*139 956.9*176.5*17.9 1000:1 LVDS (2 ch, 8-bit)
37.17 LCMA-RX3717TL01-C075 750 (0-50) 1920*159 941.19*77MM 975.6*110*27MM 1200:1 LVDS (2 ch, 8-bit)
37.6 LCMA-RX0376TI01-Z200 2000 (-10-70) 1920*540 919.3 kali 258.55 947.3*293.55*55 3000:1 LVDS (2 ch, 8-bit)
37.8 LCMA-RX0378TL01-C200 2000 (0-50) 1920*387 941.18*190 968.9 x 218 x 26.9 1200:1 LVDS (2 ch, 8-bit)
38 LCMA-RX0380TB01-C070 700 (-20-70) 1920*540 919.3*258 955.9*304.6*19 1000:1 LVDS (2 ch, 8-bit)
43 LCMA-RX0430TL01-Z200 2000 (0-50) 1920*360 1073.78*201.34 1104*227.5*50 1300:1 LVDS (2 ch, 8/10-bit)
43.5 LCMA-RX0435TI01-C100 1000 (0-50) 1920*268 1095.84*153 1121.7*184.8*21.6 5000:1 LVDS (2 ch, 8-bit)
43.9 LCMA-RX0439TL02-C070 700 (0-50) 1920*540 1073.78*302 1105*337*49 1100:1 V-by-One 8 jalur
43.9 LCMA-RX0439TQ01-C100 1000 (-10-70) 1920*540 1073.78*302 1105*337*21   LVDS (2 ch, 8-bit)
47.8 LCMA-RX0478TB01-C160 1600 (-20-70) 1920*178 1209.6*112.1 1244.6*151.5*23.9 1000:1 LVDS (2 ch, 10-bit)
47.95 LCMA-RX04795TB01-C070 700 (-20-70) 1920*238 1209.6*150 1249.2*190*25*27 1000:1 LVDS (2 ch, 10-bit)
48 LCMA-RX0480TL01-C070 700 (-20-65) 1920*238 1209.6 kali 680.4 1249.1*189.9*25.6 1300:1
48.45 LCMA-RX04845TL01-C070 700 (0-50) 3840*270 1209.6 kali 680.4 1240*257.2*28.2 1300:1 V-by-One 8 jalur
48.6 LCMA-RX0486TL01-C070 700 (0-50) 3840*2160 1209.6 x 257.7 1225.8*280*25 1300:1 V-by-One 8 jalur
49.5 LCMA-RX0495TL01-C025 250 (0-50) 3840*1080 1209.6 kali 340.2 1241.45*364.7*26 1300:1 V-by-One 8 jalur
49.5 LCMA-RX0495TL02-C100 1000 (0-50) 1920*540 1209.6 kali 340.2 1240.2*370.8*24.5 1300:1 V-by-One 8 jalur
49.5 LCMA-RX0495TB66-C025 250 (0-50) 3840*1080 1209.6 kali 340.2 1376*365.5*38.5 1300:1 V-by-One 8 jalur
49.5 LCMA-RX0495TB09-C100 1000 (-20-70) 1920*540 1209.6 kali 340.2 1228*385*31.8 1000:1 LVDS (2 ch, 10-bit)
50.4 LCMA-RX0504TL01-C050 500 (-20-70) 3840*1334 1209.6*420 1233.59*450*33.9 1300:1 V-by-One 8 jalur
50.53 LCMA-RX5053TL01-C070 700 (-20-60) 3840*536 1270.08*721.44 1301.5*209.42*28.2 ₹ 5000:1 V-by-One 8 jalur
56.6 LCMA-RX0566TL04-C100 1000 (-20-70) 3840*470 1428.48*175 1461*204*21.9 1300:1 V-by-One 8 jalur
57.4 LCMA-RX0574TL01-C100 1000 (0-50) 3840*810 1428.48*301.32 1469.5*343.2*18.5 1300:1 120 pin EPI
58.4 LCAM-RX0584TL01-C200 2000 (0-50) 3840*1080 1428.48 kali 401.76 1470*406*29.6 1300:1 V-by-One 8 jalur
65.3 LCMA-RX0653TL01-C100 1000 (0-50) 3840*412 1649.66*177 1654.66*181.95*23.5 1400:1 V-by-One 16 jalur
69.3 LCMA-RX0693TL01-C100 1000 (0-50) 3840*1440 1649.66*618.62 1653.66*622.62*29 1400:1 V-by-One 16 jalur
88 LCMA-RX0880GL01-Z150 1000 0 ~ 50 3840*1080 2158.85 kali 607.18 2202 kali 650 kali 48.4 1200:1 V-by-One 8 jalur

Keuntungan Produk

1. 3 set mesin pemotong, 2 jalur produksi pemotong canggih, yang terpanjang dapat dipotong hingga 1,7 m (pemotong 75 inci).
2Teknologi pemotongan canggih untuk memastikan hasil dan presisi.
3Keandalan tinggi dengan fitur yang sama dengan panel asli.
4Anti-getaran tinggi.
5. Kecerahan dapat disesuaikan (500-2500nit).
6. Waktu hidup panjang 50K jam ((jenis), hingga 80K jam.

Aplikasi produk️

1Tanda sosial: Iklan dan Harga Rak.
2Transportasi umum: Papan tagihan untuk Bus/Metro dan rel ringan.
3Papan panduan, papan iklan lift.
4Layanan keuangan, papan pengumuman panggilan bank.
5Kartu nama.
6Papan iklan di taksi.

Tampilan LCD Tipe Bar Cerah Tinggi dalam 9-88 "Ukuran Panel dan 500-2500 Tipe Cerah 0 Tampilan LCD Tipe Bar Cerah Tinggi dalam 9-88 "Ukuran Panel dan 500-2500 Tipe Cerah 1 Tampilan LCD Tipe Bar Cerah Tinggi dalam 9-88 "Ukuran Panel dan 500-2500 Tipe Cerah 2 Tampilan LCD Tipe Bar Cerah Tinggi dalam 9-88 "Ukuran Panel dan 500-2500 Tipe Cerah 3

️Katalog produk layar LCD tipe batang.pdf
